Motorola CP1660 Commercial Two-Way Radio – Factory Wholesale | VHF/UHF Portable Radio 99 Channels Full Keypad IP54 VOX
The Motorola CP1660 is a high-performance commercial radio with a full keypad for easy frequency management. Offering crystal-clear audio and a rugged design, it’s ideal for hospitality, security, and manufacturing. Source directly from our factory for the best wholesale prices and guaranteed premium quality.
Maximize Efficiency with the Motorola CP1660 Commercial Radio
The Motorola CP1660 is designed to provide reliable, high-quality communication for your business. Featuring a full alphanumeric keypad and a clear display, this radio allows for quick channel switching and feature access, making it a favorite for supervisors and team leaders in demanding environments.
Why the Motorola CP1660 Stands Out:
- Enhanced Functionality: The full keypad and display screen allow users to easily manage up to 99 channels and customize settings on the go.
- Crystal Clear Audio: Built with Motorola’s X-Pand™ technology, the CP1660 delivers loud and clear voice quality even in noisy industrial backgrounds.
- Military-Grade Durability: Built to meet MIL-STD 810C/D/E/F/G standards, ensuring it can handle drops, dust, and harsh weather.
- Long-Lasting Power: High-capacity Li-ion batteries provide over 11 hours of talk time to cover full work shifts.
Factory Wholesale Advantage on twowayradio.cc:
As a specialized communication equipment supplier, we offer the Motorola CP1660 at direct factory wholesale prices. We ensure every unit undergoes rigorous quality control to meet premium quality standards. Whether you are a reseller or an enterprise buyer, our bulk shipping options and competitive pricing provide the best value in the market.
Technical Specifications:
- Frequency Range: VHF (136-174MHz) or UHF (403-447MHz / 435-480MHz).
- Channel Capacity: 99 Channels for large-scale coordination.
- Programmable Buttons: 5 programmable buttons for one-touch access to your most-used features.
- Hands-Free Ready: Built-in VOX capability for hands-free communication with compatible accessories.
Main features
Dual-band Flexible Deployment
99 Channels + Full-Size Keyboard
Noise Immunity and Privacy
VOX hands-free mode and five programmable side buttons enable one-touch activation of 10 functions (panic alarm, scanner on/off, power on/off, etc.), conveniently integrating with access control and IoT alarms.
Talk-around mode allows you to maintain group calls even without a repeater, reducing project budgets.
IP54 rainproof and MIL-STD-810 C/D/E/F rated for impact, dust, and humidity, reducing ongoing maintenance costs.
Other functions
-
VOX hands-free
-
2 program keys
-
Direct mode
-
DTMF ID & call
-
IP54 MIL-STD
-
Numeric keypad
-
Large PTT
-
LCD icons
-
X-Pand audio
- Battery(PMNN4080 2200 mAh)
- Antenna(VHF/UHF)
- Lanyard
- Back Clip
- Charger
- Power adaptor
- Manual
Specifications
| General | ||
|---|---|---|
| Feature | VHF | UHF |
| Frequency Range | 136–174 MHz | 403–446 MHz / 435–480 MHz |
| Memory Channels: 99 | Channel Spacing: 12.5/25 kHz | ||
| Operating Temperature: –30 °C to +60 °C | Sealing: IP54 | Shock/Vibration: MIL-STD-810 C/D/E/F | ||
| Dimensions (H×W×D) | Li-Ion: 120×55×35.5 mm NiMH: 120×55×36.5 mm High-Cap Li-Ion: 120×55×40.7 mm |
|
| Weight | Li-Ion: 335 g | NiMH: 394.5 g | High-Cap Li-Ion: 342 g | |
| Battery Life (5-5-90 cycle): up to 11 hrs (Li-Ion), 9 hrs (NiMH), 16 hrs (High-Cap Li-Ion) | ||
| Transmitter | ||
| RF Output | 5 W High / 1 W Low | 4 W High / 1 W Low |
| Spurs & Harmonics: < –36 dBm (≤1 GHz), < –30 dBm (>1 GHz) Frequency Stability: ±2.5 ppm (-30 °C to +60 °C) FM Hum & Noise: >40 dB | Audio Distortion: <5 % Modulation Limiting: ≤5 kHz (25 kHz), ≤2.5 kHz (12.5 kHz) |
||
| Receiver | ||
| Sensitivity:<-119 dBm (0.25 μV) Adjacent Channel Selectivity: >70 dB (25 kHz) / >65 dB (12.5 kHz) Intermodulation: >70 dB | Spurious Rejection: >70 dB Audio Distortion: <5 % | Audio Output: 500 mW @ 24 Ω |
||
